FOXcrystal超小型石英晶体谐振器具有紧凑封装的显着性能
来源：http://www.yddxqf.cn 作者：泰河电子晶振 2018年05月23
Ultra-low Profile Tuning ForkOffers Significant Performance in Compact Package
Fox’s new SMD crystal ideal for handheld and portable applications.
Fort Myers, Fla. May 2015 – Fox Electronics, a leading global supplier of frequency control solutions and an IDT company, has developed its most compact watch crystal, measuring just 1.6 mm x 1.1 mm x 0.5 mm (L x W x H).
Although smaller in size, the new FX161 crystal operates at many of the same high standards as previous models, making it one of the most efficient tuning forks yet.
The crystal’s ultra-low profile and exceptional performance optimizes the minimal space available in many portable and handheld applications, including wearable devices.
The new surface mount device (SMD) operates at a frequency of 32.768 kHz. Frequency tolerance is ±20 ppm at 25°C with a long term of -0.046 ppm per Delta C2. Standard load capacitance is 12.5 pF, with optional 7 pF or 9 pF available.
The new tuning fork ages only ±3 ppm in the first year, and features a termination finish of gold over nickel. Overall operating temperature range is -40°C to +85°C with a turnover temperature range of +20°C to +30°C and a storage temperature of -55°C to +125°C. Maximum soldering is 10 seconds at 260°C.
The new watch crystal sustains a maximum of 90 kilo-ohms equivalent series resistance and an insulation resistance of 500 mega-ohms at 100 VDC.
FOXcrystal超小型石英晶体谐振器具有紧凑封装的显着性能
紧凑包装福克斯的新型SMD晶体非常适合手持和便携式应用。
美国佛罗里达州迈尔斯堡2015年5月 - 全球领先的变频控制解决方案供应商福克斯晶振电子与IDT公司合作开发出尺寸仅为1.6毫米x1.1毫米x0.5毫米（长x宽x高）的最紧凑型手表晶体。
尽管尺寸较小，但新型FX161晶振的运行速度与之前的几款相同，仍然是最高效的调谐分支之一。
该晶体的超薄外形和卓越的性能优化了许多便携式和手持式应用（包括可穿戴设备）的最小空间。
新型表面贴装器件（SMD）的工作频率为32.768kHz。频率容限在25°C时为±20 ppm，每个Delta C2长期为-0.046 ppm。标准负载电容为12.5 pF，可选7 pF或9 pF。
新的音叉在第一年的年龄仅为±3 ppm，并且具有金镍以上的终止表面处理。整体工作温度范围为-40°C至+ 85°C，并具有周转温度+ 20°C至+ 30°C的范围和-55°C至+ 125°C的储存温度。 260°C时最大焊接时间为10秒。
新型手表晶体可承受最高90千欧姆的等效串联电阻和100 VDC时的500兆欧姆绝缘电阻。
