Key Differences	Automotive	Consumer/Industrial
Identification	“A” product series Documents marked “ACAP”	Other than “A” product series
Engineer/Operators	Automotive training program with qualification level, dedicated full time	TXC standard training program
Production Line	Dedicated	Mix
Reliability	Automotive grade AEC-Q100 & AEC-Q200 + customer requirement	Consumer grade + customer requirement
New product design to manufacturing	Advance Product Quality Planning (APQP)
Specification	-40 to 105C, 125C and 150C	-40 to 85C, 105C or by customer specification
Final test	100%	Based on customer requirement
Qualification process	PPAP, PSW (TXC PQSO)	TXC PQSO
Record retention	15 years	5 years
Quality Assurance system	ISO/TS16949, VDA6.3	QS9001, ISO/TS16949

Automotive Product Series, Customized Specs is Available

Type	Product Series	Frequency Range	Temperature Range	Manufacturing
Crystal	AS (HC-49S)	4~62.4MHz	-40~+105℃	China
	AT (HC-49S/SMD)	4~62.4MHz	-40~+105℃
	AX (8045 Glass)	6~40MHz	-40~+150℃
	AA (5032 Glass)	8~48MHz	-40~+150℃
	AV (3225 Glass)	9.84~62.4Mhz	-40~+125℃
	AH (3215 Seam)	32.768kHz	-40~+125℃
	AB (5032 Seam)	8~50MHz	-40~+125℃	Taiwan
	AM (3225 Seam)	10~50MHz	-40~+125℃
	AZ (2520 Seam)	16~80MHz	-40~+125℃
	AY (2016 Seam)	16~50MHz	-40~+125℃
XO (CMOS)	AC (5032 Seam)	1~70MHz	-40~+105℃	Taiwan
	AU (3225 Seam)	1~70MHz	-40~+125℃
	AW (2520 Seam)	4~54MHz	-40~+125℃
TCXO	AQ (3225Seam)	13~52MHz	-40~+105℃
TCXO	AL(2520 Seam)	13~52MHz	-40~+105℃
TSX	AE(2520 Seam)	19.2MHz	-40~+105℃

AECQ – What is AECQ?
AEC is an abbreviation of "Automotive Electronics Council." AEC is an industry organization that promotes the standardization of reliability or qualification standards for automotive electronic components, consisting of major auto manufacturers and major electronic component manufacturers in the USA. The AEC-Qxxx standards are widely adopted as standards for automotive electronic components, practically serving as the industry standards.These standards are classified into the following groups,according to the component category:
AEC-Q100: Integrated circuits (ICs)
AEC-Q200: Passive components (capacitors, inductors, etc.)石英晶振

PPAP – What is PPAP?
Production Part Approval Process (PPAP) is a standardized process in the automotive and aerospace industries that helps manufacturers and suppliers communicate and approve production designs and processes before, during, and after manufacture.
OTR – Why the need of wider Operating Temperature Range?
An operating temperature is the temperature at which an electrical or mechanical device operates. The device will operate effectively within a specified temperature range which varies based on the device function and application context, and ranges from the minimum operating temperature to the maximum operating temperature (or peak operating temperature). Outside this range of safe operating temperatures the device may fail. Automotive generally operate over a broader temperature range than industrial devices; commercial-grade devices generally have the narrowest operating temperature range.
Please refer to the Automotive grading chart.石英晶体振荡器
Automotive Record Retention – Why is longer time-frame?
Automotive Electronics suppliers are required to be certified under TS-16949 & ISO9001, under TS & ISO system there’s a standard requirement for record retention set by OEM car manufacturers.

Production – Why automotive has dedicated production line?
Automotive Timing device is put into dedicated production line due to the fact that the quality standard differs from consumer applications. Automotive tier one customers uses “Zero Defect” concept (0ppm) to audit its suppliers, as well as mandating its suppliers to implement the same concept into its subtiers. Production control processes are more stringent than the ones producing consumer products.
Zero Defects (or ZD) was a management-led program to eliminate defects in industrial production that enjoyed brief popularity in American industry from 1964[1] to the early 1970s. Quality expert Philip Crosby later incorporated it into his "Absolutes of Quality Management" and it enjoyed a renaissance in the American

TXC原厂编码	生产厂家	型号	频率	频率稳定度	频率偏差	负载电容	工作温度
9HT7-32.768KDZF-T	TXC晶振	9HT7	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
9HT7-32.768KDZF-T	TXC晶振	9HT7	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
9HT7-32.768KDZF-T	TXC晶振	9HT7	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
9HT10-32.768KBZF-T	TXC晶振	9HT10	32.768kHz	-	±50ppm	12.5pF	-40°C ~ 85°C
9HT10-32.768KBZF-T	TXC晶振	9HT10	32.768kHz	-	±50ppm	12.5pF	-40°C ~ 85°C
9HT10-32.768KBZF-T	TXC晶振	9HT10	32.768kHz	-	±50ppm	12.5pF	-40°C ~ 85°C
9HT10-32.768KDZF-T	TXC晶振	9HT10	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
9HT10-32.768KDZF-T	TXC晶振	9HT10	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
9HT10-32.768KDZF-T	TXC晶振	9HT10	32.768kHz	-	±20ppm	12.5pF	-40°C ~ 85°C
9HT10-32.768KEZF-T	TXC晶振	9HT10	32.768kHz	-	±10ppm	12.5pF	-40°C ~ 85°C
9HT10-32.768KEZF-T	TXC晶振	9HT10	32.768kHz	-	±10ppm	12.5pF	-40°C ~ 85°C
9HT10-32.768KEZF-T	TXC晶振	9HT10	32.768kHz	-	±10ppm	12.5pF	-40°C ~ 85°C
7A-27.120MAAE-T	TXC晶振	7A	27.12MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7A-27.120MAAE-T	TXC晶振	7A	27.12MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7A-27.120MAAE-T	TXC晶振	7A	27.12MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7A-24.000MAAJ-T	TXC晶振	7A	24MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-24.000MAAJ-T	TXC晶振	7A	24MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-24.000MAAJ-T	TXC晶振	7A	24MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-16.000MAAJ-T	TXC晶振	7A	16MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-16.000MAAJ-T	TXC晶振	7A	16MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-16.000MAAJ-T	TXC晶振	7A	16MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-8.000MAAJ-T	TXC晶振	7A	8MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-8.000MAAJ-T	TXC晶振	7A	8MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-8.000MAAJ-T	TXC晶振	7A	8MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-12.000MAAJ-T	TXC晶振	7A	12MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-12.000MAAJ-T	TXC晶振	7A	12MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-12.000MAAJ-T	TXC晶振	7A	12MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-25.000MAAJ-T	TXC晶振	7A	25MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-25.000MAAJ-T	TXC晶振	7A	25MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-25.000MAAJ-T	TXC晶振	7A	25MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-27.120MAAJ-T	TXC晶振	7A	27.12MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-27.120MAAJ-T	TXC晶振	7A	27.12MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-27.120MAAJ-T	TXC晶振	7A	27.12MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-24.000MAHE-T	TXC晶振	7A	24MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
7A-24.000MAHE-T	TXC晶振	7A	24MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
7A-24.000MAHE-T	TXC晶振	7A	24MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
7A-10.000MAAJ-T	TXC晶振	7A	10MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-10.000MAAJ-T	TXC晶振	7A	10MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7A-10.000MAAJ-T	TXC晶振	7A	10MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
8Z-27.120MAAV-T	TXC晶振	8Z	27.12MHz	±30ppm	±30ppm	8pF	-20°C ~ 70°C
8Z-27.120MAAV-T	TXC晶振	8Z	27.12MHz	±30ppm	±30ppm	8pF	-20°C ~ 70°C
8Z-27.120MAAV-T	TXC晶振	8Z	27.12MHz	±30ppm	±30ppm	8pF	-20°C ~ 70°C
8Y-16.000MAAV-T	TXC晶振	8Y	16MHz	±30ppm	±30ppm	8pF	-20°C ~ 70°C
8Y-16.000MAAV-T	TXC晶振	8Y	16MHz	±30ppm	±30ppm	8pF	-20°C ~ 70°C
8Y-16.000MAAV-T	TXC晶振	8Y	16MHz	±30ppm	±30ppm	8pF	-20°C ~ 70°C
7V-12.000MAAE-T	TXC晶振	7V	12MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-12.000MAAE-T	TXC晶振	7V	12MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-12.000MAAE-T	TXC晶振	7V	12MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-24.000MAAE-T	TXC晶振	7V	24MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-24.000MAAE-T	TXC晶振	7V	24MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-24.000MAAE-T	TXC晶振	7V	24MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-16.000MAAE-T	TXC晶振	7V	16MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-16.000MAAE-T	TXC晶振	7V	16MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-16.000MAAE-T	TXC晶振	7V	16MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-25.000MAAE-T	TXC晶振	7V	25MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-25.000MAAE-T	TXC晶振	7V	25MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-25.000MAAE-T	TXC晶振	7V	25MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
7V-12.000MAHE-T	TXC晶振	7V	12MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
7V-12.000MAHE-T	TXC晶振	7V	12MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
7V-12.000MAHE-T	TXC晶振	7V	12MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
AA-8.000MALV-T	TXC晶振	AA	8MHz	±150ppm	±30ppm	8pF	-40°C ~ 125°C
AA-8.000MALV-T	TXC晶振	AA	8MHz	±150ppm	±30ppm	8pF	-40°C ~ 125°C
AA-8.000MALV-T	TXC晶振	AA	8MHz	±150ppm	±30ppm	8pF	-40°C ~ 125°C
7B-8.000MAAJ-T	TXC晶振	7B	8MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7B-8.000MAAJ-T	TXC晶振	7B	8MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7B-8.000MAAJ-T	TXC晶振	7B	8MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7B-12.000MAAJ-T	TXC晶振	7B	12MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7B-12.000MAAJ-T	TXC晶振	7B	12MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7B-12.000MAAJ-T	TXC晶振	7B	12MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7B-25.000MAAJ-T	TXC晶振	7B	25MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7B-25.000MAAJ-T	TXC晶振	7B	25MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7B-25.000MAAJ-T	TXC晶振	7B	25MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
7B-24.000MAAJ-T	TXC晶振	7B	24MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
